HOME > Imported Product > Ring blower
•Side channel blowers have been widely used in the environmental water treatment. For example, in the aeration of sewage, ring blowers can provide oxy that the aerobe need in the activated sludge. Also, blowers can provide the conditions which make the sewage and activated sludge mixed sufficiently to dissolve all kinds of organic matters in the water. Then, the sewage water can be purified. Besides the above, ring blowers can also be used to mix the plating bath fluid and can be used in the aquaculture industry as well in the printer industry.



2RB Single stage Ring Blower

Maximum Flow at         : 2,200 m3/hr
Maximum Pressure at  :    500 mBar
(Motor Electrical frequency at 50 Hz)






2RB Double stage Ring Blower

Maximum Flow at         : 2,100 m3/hr
Maximum Pressure at  :    590 mBar
(Motor Electrical frequency at 50 Hz)






2RB Single stage Ring Blower
Belt Drive Version

Maximum Flow at         : 2,700 m3/hr
Maximum Pressure at  :    500 mBar
(Motor Electrical frequency at 50 Hz)






2RB Double stage Ring Blower
Belt Drive Version

Maximum Flow at         : 860 m3/hr
Maximum Pressure at  :    750 mBar
(Motor Electrical frequency at 50 Hz)






2RB Three stage Ring Blower
Belt Drive Version

Maximum Flow at         : 3200 m3/hr
Maximum Pressure at  :    220 mBar
(Motor Electrical frequency at 50 Hz)






3RB Double stage Ring Blower

Maximum Flow at         : 700 m3/hr
Maximum Pressure at  :    860 mBar
(Motor Electrical frequency at 50 Hz)






3RB Three Stage Ring Blower

Maximum Flow at         : 700 m3/hr
Maximum Pressure at  :    1,020 mBar
(Motor Electrical frequency at 50 Hz)






4RB Single stage Ring Blower

Maximum Flow at         : 165 m3/hr
Maximum Pressure at  :    480 mBar
(Motor Electrical frequency at 50 Hz)






4RB Double stage Ring Blower

Maximum Flow at         : 165 m3/hr
Maximum Pressure at  :  1,000 mBar
(Motor Electrical frequency at 50 Hz)






4RB Three stage Ring Blower

Maximum Flow at         : 170 m3/hr
Maximum Pressure at  :  1,050 mBar
(Motor Electrical frequency at 50 Hz)


    Download Brochure >> Ring Blower (GreenCo)
